配置

技术规格

数量

目镜

大视野 PLAN 10X (视场数25mm） FN25

2pcs

平场无限远消色差明暗场物镜

PLAN lnflnity 5X BD NA 0.1, WD 16.6

PLAN lnflnity 10X BD NA 0.25, WD 16.0

PLAN lnflnity 20X BD NA 0.40, WD 10.5

PLAN lnflnity 50X BD NA 0.55, WD 5.1

PLAN lnflnity 100X BD NA 0.80, WD 3.01

1pcs

1pcs

1pcs

1pcs

1pcs

C--Mount

1X

1pcs

三目镜筒

Trinocular tube and C-mount

Interpupillary distance 55mm-75mm 0.7x或1X C-mount

U-CTR30-2 Trinocular tube, FN25, fixed light pass, Bi/Photo: 50/50 100/0 0/100

1pcs

调焦机构

Foucus system

粗微动同轴调焦，微动格值：1~4微米可变，带锁紧和限位,最大行程30mm，可放置试样高度40mm

Coaxial coarse/fine focus system,with tension adjustable and limit stopper.

minimum division of fine focusing 1~4mm，Maximum stroke 30mm, the specimen height 40mm

1pcs

显微镜镜体

Microscope system

10w 高效率白色LED 色温温和 包含转换器 滤色片 明暗场切换装置 可调视场光阑

Microscope frame with quintuplerevolving nosepiece,

mechanicalstage（right handle）, 10w led illuminator, filter 32.5C-2.

Corresponded to WEEE regulation，Switching device for dark field Adjustable field aperture

1pcs

转换器

Nosepiece

五孔 转换器

Nosepiece 5 hole

1pcs

左右手操作可切换，高低位可调工作台

The left and right hand operation

can be switched, high and low

X 行程 77mm Y 行程 55mm

adjustable stage

X trip 77mm Y trip 55mm

1pcs

落射照明系统

Epi-illumination system

10w LED照明，内置偏移式视场光阑，孔径光阑，推拉式检偏器与起偏器

10w led illuminator,Built-in offset field aperture, aperture aperture，

push-pull type detector, and bias

1pcs

聚光镜

Brightfield condenser

阿贝聚光镜NA0.9 上下可升降 可调孔径光阑

Brightfield condenser, N.A. 0.9, Up and down adjustable Adjustable aperture

1pcs

滤色片

Filter

Blue Green and yellow frosted glass

3pcs

电源 Power

100v~240v输入 100 v to 240 v input AC

1pcs
